• High-performance 8-channel Plug & Play upgrade amplifier with integrated 9-channel 64 Bit DSP for significantly more power and dynamics
• Specially developed for BMW E & F as well as G30 / G31 (pre-facelift) models with BMW HiFi sound system (Option 676)
• Easy and seamless installation at the original mounting location via included Plug & Play connection cable and mounting plate*
• Perfectly combinable with MATCH UPGRADE components – subwoofer, 2-way system & center speaker
• ACO – Advanced 32 Bit CoProcessor platform for extended feature set
• ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals
• Proprietary TuneEQ function for automated adjustment of the output equalizers
• SFX (DSP Sound Effects) – Augmented Bass Processing, RealCenter & Co.
• MEC slot for system expansions like Bluetooth® HD Audio Streaming, High Resolution Audio Streaming via USB etc.
• Start-Stop capability down to 6V supply voltage
• Mono RCA output for the connection of an external amplifier e.g. subwoofer amplifier MATCH UP 1FX
• Optical input in SPDIF format with sampling rate between 12 and 96 kHz
• SCP (Smart Control Port) for optional accessory like DIRECTOR, CONDUCTOR & Co.
• Easiest configuration via the intuitive DSP PC-Tool Software incl. VCP (Virtual Channel Processing) and TuneEQ

* Mounting plate not suitable for 1-series E models

Special Features:

Class GD technology

Audiotec Fischer´s proprietary Class GD concept takes the efficiency of conventional Class D amps to the next level. By varying the internal supply voltage in several steps depending on the amplifier’s input signals, idle losses are significantly reduced and overall efficiency is close to maximum at any time. So heat dissipation is almost negligible, thus allowing smallest heat sinks and most compact form factors.

ACO – Advanced 32 Bit CoProcessor

The UP 8BMW incorporates an extraordinary powerful 32 Bit CoProcessor of the latest generation. This not only takes over all control tasks ultra-fast, but also the lightning-fast switching between up to ten possible sound setups.
But ACO offers much more – besides a channel-separated Input EQ including Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios and fantastic sound effects like Augmented Bass Processing or RealCenter, there is now the revolutionary TuneEQ function for automated adjustment of the output equalizers.
A further significant advantage is the integrated, native boot loader of the CoProcessor. It allows software upgrades of all components of the DSP in order to adjust the microcontroller-controlled ADEP.3 circuit for example at future modifications / changes in the diagnostic system of factory radios or if the device will be extended with additional interfaces.

Smart highlevel input ADEP.3

Modern, factory-installed car radios incorporate sophisticated possibilities of diagnosing the connected speakers. In particular the latest generation of BMW car radios are equipped with additional monitoring functions so that failure messages and loss of specific features (e.g. fader function) quite often appear if a common amplifier will be hooked up – but not with the UP 8BMW.

The new ADEP.3 circuit (Advanced Diagnostics Error Protection, 3rd Generation) avoids all these problems without loading the speaker outputs of the OE radio during high volumes unnecessarily.

Start-Stop capability

The switched power supply of the MATCH UP 8BMW assures a constant internal supply voltage even if the battery’s voltage drops to 6 Volts during engine crank. If the supply voltage drops below 10.5 Volts for more than five seconds the amplifier goes to “Protect mode” (Status LED lights up red) in order to avoid any further discharge of the car’s battery.

Automatic Digital Signal Detection

Switching from analog input to the digital input is done automatically as soon as a signal is detected on the Optical Input. This feature can be deactivated in the DSP PC-Tool software. Alternatively you can use an optional remote control for manual switching between analog and digital inputs.

Power Save Mode

The Power Save Mode is incorporated in the basic setup. It allows to significantly reduce the power consumption of the UP 8BMW and potentially connected amplifiers once there’s no input signal present for more than 60 seconds. Please note that in many up-to-date cars with “CAN” or any other internal bus structures it may happen that the radio remains “invisibly” turned on for up to 45 min. even after locking and leaving the car! Once the “Power Save Mode“ is active the remote output and therefore the connected amplifiers will be turned off. The MATCH UP 8BMW will reactivate the remote output within a second if a music signal is applied. It is possible to either modify the turn-off time of 60 sec. or completely deactivate the “Power Save Mode” via the DSP PC-Tool software.
